IslandBridge Dock(er)s and (z)Waves

In the previous article in the series, I briefly went over what I wanted to set up: a Z-Wave and Zigbee to Home Assistant bridge. That was two years ago. As often happens, I just dove in and didn't take many notes along the way. However, I can say with certainty that this has worked very well for the last two years! Below are the configs that I have been using.

Zigbee2mqtt docker-compose.yaml

version: '3.8'
services:
  zigbee2mqtt:
    restart: unless-stopped
    image: koenkk/zigbee2mqtt
    volumes:
      - ./data:/app/data
      - /run/udev:/run/udev:ro
    environment:
      - TZ=America/New_York
    devices:
      - '/dev/serial/by-id/usb-dresden_elektronik_ingenieurtechnik_GmbH_ConBee_II_DE2400118-if00:/dev/ttyACM0'
    labels:
      - "traefik.http.routers.zigbee2mqtt.rule=Host(`zigbee2mqtt.internal.murawsky.net`)"
      - "traefik.http.services.zigbee2mqtt.loadbalancer.server.port=8080"
    networks:
      - web

networks:
  web:
    external: true

zwavejs2mqtt docker-compose.yaml

version: "3.7"
services:
  zwavejs2mqtt:
    container_name: zwavejsui
    image: zwavejs/zwave-js-ui:latest
    restart: unless-stopped
    tty: true
    stop_signal: SIGINT
    environment:
      - ZWAVEJS_EXTERNAL_CONFIG=/usr/src/app/store/.config-db
      - TZ=America/New_York
    env_file:
      - ./secrets.env
    devices:
      # Do not use /dev/ttyUSBX serial devices, as those mappings can change over time.
      # Instead, use the /dev/serial/by-id/X serial device for your Z-Wave stick.
      - '/dev/serial/by-id/usb-Silicon_Labs_Zooz_ZST10_700_Z-Wave_Stick_0001-if00-port0:/dev/zwave'
    volumes:
      - zwave-config:/usr/src/app/store
    ports:
      - "3000:3000" # port for Z-Wave JS websocket server
    labels:
      - "traefik.http.routers.zwavejs2mqtt.rule=Host(`zwavejs2mqtt.internal.murawsky.net`)"
      - "traefik.http.services.zwavejs2mqtt.loadbalancer.server.port=8091"
    networks:
      - web

networks:
  web:
    external: true

volumes:
  zwave-config:
    name: zwave-config

Traefik docker-compose.yaml

Both services exist behind the traefik reverse proxy, also running via docker.

version: '3'
services:
  reverse-proxy:
    # The official v2 Traefik docker image
    image: traefik:v2.8
    restart: unless-stopped
    # Enables the web UI and tells Traefik to listen to docker
    # --serverstransport.insecureskipverify=true
    command: --api.insecure=true --providers.docker --metrics.prometheus=true
    ports:
      # The HTTP port
      - "80:80"
      # The Web UI (enabled by --api.insecure=true)
      - "8080:8080"
    volumes:
      # So that Traefik can listen to the Docker events
      - /var/run/docker.sock:/var/run/docker.sock
    networks:
      - web

networks:
  web:
    external: true

Closing Thoughts

Better late than never! 😆 This system has worked very well with almost no hiccups at all. It integrated easily with Home Assistant as well.
